SAVATRONIC® - LiYY |
|
PVC data cable |
 |
| |
Construction |
|
|
| |
Conductor |
|
bare copper strands |
| |
|
|
with reference to DIN VDE 0812 |
| |
Insulation |
|
PVC, YI2 acc. to DIN VDE 0207 part 4 |
| |
Core code |
|
with reference to DIN 47100 |
| |
Stranding |
|
in layers |
| |
Sheath material |
|
PVC, YM1 acc. to DIN VDE 0207 part 5 |
| |
Sheath colour |
|
grey (RAL 7032) |
| |
|
|
|
| |
Technical data |
|
|
| |
Peak operating voltage |
|
250V |
| |
Testing voltage |
|
0.14mm²= 1200V |
| |
|
|
>0.14mm²= 1500V |
| |
Min. bending radius |
|
|
| |
fixed laying |
|
12 x d |
| |
Capacitance |
|
120nF/km |
| |
Radiation resistance |
|
8 x 107 cJ/kg |
| |
Temperature range |
|
|
| |
fixed laying |
|
-30/+70°C |
| |
flexible application |
|
-5/+70°C |
| |
Fire performance |
|
flame retardant and self-extinguishing |
| |
|
|
acc. to IEC 60332-1 + EN 50265-2-1 + |
| |
|
|
VDE 0482 part 265-2-1 |
| |
Oil resistance |
|
acc. to internal standard |
| |
Chem. resistance |
|
|
| |
|
|
|
| |
Application |
|
|
| |
|
|
|
| |
 |
| |
