SAVATRONIC® - Profibus-DP |
|
|
 |
| |
Construction |
|
|
| |
Conductor |
|
bare solid wire |
| |
|
|
AWG 22/1(0.64mm) |
| |
Insulation |
|
foamed PE 2.55mm |
| |
Stranding |
|
two cores to a pair |
| |
Screen |
|
aluminium tape + tinned braind |
| |
Sheath |
|
PVC violet 8.0+/-0.4mm |
| |
|
|
|
| |
Technical data |
|
|
| |
Peak operating voltage |
|
350 V |
| |
Testing voltage |
|
1500 V |
| |
Impedance |
|
150 Ohm+/-10% (AWG 22) |
| |
 |
| |
